单线对及双线对线路传输级模拟音频电缆

General Description:

22 AWG stranded (7x30) TC conductors, polyethylene insulation, twisted pair, overall Beldfoil. shield (100% coverage), 22 AWG stranded TC drain wire, PVC jacket.



Physical Characteristics (Overall)

Conductor

AWG:

# Pairs      AWG     Stranding     Conductor Material

1               22          7x30            TC - Tinned Copper

Total Number of Conductors:                                 2



Insulation

Insulation Material:

Insulation Material                Wall Thickness (in.)

PE - Polyethylene                  0.017



Outer Shield

Outer Shield Material:

Outer Shield Trade Name     Type     Outer Shield Material           Coverage (%)

Beldfoil.                                 Tape     Aluminum Foil-Polyester         100.000

                                                           Tape w/shorting fold



Outer Shield Drain Wire AWG:

AWG      Stranding      Drain Wire Conductor Material

22          Stranded       TC - Tinned Copper



Outer Jacket

Outer Jacket Material:

Outer Jacket Material              Nom. Wall Thickness (in.)

PVC - Polyvinyl Chloride          .025



Overall Cable

Overall Cabling Lay Length & Direction:

Length (in.)       Direction        Twists (twist/ft)

2.000                Left Hand       6.000

Overall Nominal Diameter:      0.175 in.



Pair

Pair Color Code Chart:

Number           Color

1                      Black & Clear



Mechanical Characteristics (Overall)

Operating Temperature Range:                    -20°C To +60°C

UL Temperature Rating:                                60°C (UL AWM Style 2092)

Bulk Cable Weight:                                        16 lbs/1000 ft.

Max. Recommended Pulling Tension:           27 lbs.

Min. Bend Radius/Minor Axis:                       1.750 in.



Applicable Specifications and Agency Compliance (Overall)

Applicable Standards & Environmental Programs

NEC/(UL) Specification:                                   CM

NEC Articles:                                                    800

CEC/C(UL) Specification:                                 CM

AWM Specification:                                          UL Style 2092 (300 V 60°C)

EU Directive 2011/65/EU (ROHS II):                Yes

EU CE Mark:                                                     Yes

EU Directive 2000/53/EC (ELV):                       Yes

EU Directive 2002/95/EC (RoHS):                     Yes

EU RoHS Compliance Date (mm/dd/yyyy):       01/01/2004

EU Directive 2002/96/EC (WEEE):                    Yes

EU Directive 2003/11/EC (BFR):                       Yes

CA Prop 65 (CJ for Wire & Cable):                   Yes

MII Order #39 (China RoHS):                           Yes



Flame Test

UL Flame Test:                                                 UL1685 UL Loading

CSA Flame Test:                                               FT1



Suitability

Suitability - Indoor:                                            Yes



Plenum/Non-Plenum

Plenum (Y/N):                                                    No

Plenum Number:                                               88761, 87761, 82761



Electrical Characteristics (Overall)

Nom. Characteristic Impedance:

Impedance (Ohm)

64



Nom. Inductance:

Inductance (μH/ft)

0.2



Nom. Capacitance Conductor to Conductor:

Capacitance (pF/ft)

24



Nom. Capacitance Cond. to Other Conductor & Shield:

Capacitance (pF/ft)

47



Nom. Conductor DC Resistance:

DCR @ 20°C (Ohm/1000 ft)

16



Max. Operating Voltage - UL:

Voltage

300 V RMS (UL AWM Style 2092)



Max. Recommended Current:

Description                         Current

10C temperature rise         2.9 Amps per conductor @ 25°C ambient



Put Ups and Colors:

Item #                    Putup          Ship Weight    Color            Notes        Item Desc

8761 060U1000    1,000 FT     17.000 LB       CHROME                      2 #22 PE FS PVC

8761 060U500      500 FT         9.000 LB        CHROME                      2 #22 PE FS PVC

8761 0601000       1,000 FT     18.000 LB      CHROME      C              2 #22 PE FS PVC

8761 06010000     10,000 FT   170.000 LB    CHROME      C Y           2 #22 PE FS PVC

8761 06010001     10,000 FT   170.000 LB    CHROME      C Z           2 #22 PE FS PVC

8761 06015000     15,000 FT   270.000 LB    CHROME      C Y           2 #22 PE FS PVC

8761 0602000       2,000 FT     36.000 LB      CHROME                       2 #22 PE FS PVC

8761 060500         500 FT        9.000 LB        CHROME                       2 #22 PE FS PVC

8761 0605000       5,000 FT     90.000 LB      CHROME      C              2 #22 PE FS PVC

Notes:

C = CRATE REEL PUT-UP.

Y = FINAL PUT-UP LENGTH MAY VARY -10% TO +20% FROM LENGTH SHOWN.MAY CONTAIN 2 PIECES. MINIMUM LENGTH OF ANY ONE PIECE IS 1500'.

Z = FINAL PUT-UP LENGTH MAY VARY (+ OR -) 10% FOR SPOOLS OR REELS AND(+ OR -) 5% FOR UNREEL CARTONS FROM LENGTH SHOWN.
